- Workflow: The Blueprint (The complete definition of a business process).
- Node: The Execution Unit (The individual functional steps within the process).
- Task: The Runtime Instance (The actual execution record of a workflow).
1. Workflow: The Process Blueprint
Definition: A Workflow is the end-to-end design of an automated process, representing a specific business goal. In a business context, a Workflow is equivalent to a Standard Operating Procedure (SOP). It encapsulates the complete logic, rules, and sequence of actions required to achieve a desired outcome.From Manual Operations to Automated Workflows
Consider a typical manual routine:Open e-commerce site 👉 Search for “Laptops” 👉 Iterate through 5 pages of results 👉 Extract pricing data to CSV.In BrowserAct, this entire routine is consolidated into a single Workflow (e.g., named “Price Monitor”). Once saved, this workflow becomes a reusable asset. You can execute it today for “Laptops” and tomorrow for “Keyboards” using the same underlying logic.
2. Node: The Atomic Unit of Execution
Definition: A Node is a single, concrete instruction within a Workflow. BrowserAct deconstructs complex user behaviors into granular, browser-level actions. Each component you place on the automation canvas is a Node.Mapping Manual Actions to Nodes
To automate a web task, you map your physical interactions to specific BrowserAct nodes:| Manual Interaction | BrowserAct Node |
|---|---|
| Open a URL | Visit Page |
| Type text into a field | Input Text |
| Click a button or link | Click Element |
| Scroll the viewport | Scroll Page |
| Navigate to the next page | Pagination |
| Copy text or data | Extract Data |
| Repeat actions for a list | Loop |
3. Task: The Runtime Instance
Definition: A Task is a single, independent execution record of a Workflow. A Workflow is a static design file; it does not perform actions until triggered. When you initiate a “Run,” BrowserAct generates a Task. Executing the same Workflow ten times will result in ten distinct Tasks.Anatomy of a Task
Every Task comprises four distinct components:- Inputs: The specific parameters defined for this run (e.g., Keyword: “Nike”, Max Items: 50).
- Execution Log: A chronological record of which nodes were executed, including timestamps and status codes.
- Output Data: The structured result generated by the run (JSON, CSV, etc.).
- Resource Usage: The computational resources (Credits) consumed to complete the operation.
Summary
| Concept | Definition | Function |
|---|---|---|
| Workflow | The Blueprint | Defines the complete logic and business objective. |
| Node | The Unit | Represents a specific technical action (Click, Type, Scroll). |
| Task | The Instance | Represents a single execution event with specific inputs and results. |
